JCD 110V 220V Electric Ceramic Heating Element For Soldering Iron easily control temperature
Alumina Ceramic Heater for electronic soldering iron
Introductions
Alumina Ceramic heaters were developed based on ceramic lamination technologies, which are mainly used for highly reliable IC ceramic packages. Thus, these are widely used in electronic tools .
Material performance
1.Material: Alumina 2.Maximum operation temperature :1000℃
3.Thermal conductivity (20℃): 18W/(m.K)
4.Specific heat (20℃):0.78×103 J/(kg.K)
5.Coef.of liner thermal expansion (40~800℃)
6.Vickers hardness (Load 500g):12.3 Gpa 3-point
7.flexural strength: 340 MPa
Product Specification
1.Part No.: AH60790470 2.Usage : Mainly applied to electronic soldering iron
3.Working: Voltage: 110/220 VAC
4.Heating Resistance:32.5Ω±10%
5.Dimension: Length: L30*φ3.5mm
6.Electrode: Welding Two nickel wires on the surface;
Property
1.Excellent Mechanical Properties 2.High-Temperature Durability
3.Rapid Heat Up
4.High Efficiency Heat Exchange
5.Small Size/HighOutput
