Mic Channel Controls :

• 6 Mono Mic | Line Channels XLR, ¼" Jack - Balanced
• Mic Input Impendance | 3kΩ
• Line Input Impendance | 47kΩ
• -20dB Attenuation Switch
• Gain Potentiometer
• Individual Low | 80Hz, Mid | 2.5kHz, and Hi | 15kHz, EQ Pontentiometers | -15/15 dB
• Effects Send Potentiometer
• Monitor Potentiometer
• Pan Potentiometer
• Level Fader | 60mm

Master Controls :

• 16 Digital Effects Processor
• Effects Repeat Potentiometer
• Effect Send Level Potentiometer
• Effect Level Fader | 60mm
• Monitor Send Potentiometer
• 2TK | MP3-USB Level Potentiometer, Switchable
• MP3-USB Media Player, Recorderwith LCD Screen Play, Pause, Record, Folder Select →→,←←
• Headphones Potentiometer
• 48V Phanton |Switchable Channels 1-3 and 4-6
• Individual Left and Right Master Level Faders | 60mm
• Mix Out Fader | 60mm
• 12 Bar LED Master Level | Mix Out - Monitor
• 7 Band Graphic Equaliser | /- 12 dB 100, 250,500, 1K, 2K, 4K, 8K - Hz

General

• Balanced XLR Outputs Left and Right
• Unbalanced | ¼" Jack Control Room Outputs Left and Right
• RCA Record Output Left and Right | 10kΩ
• Monitor Unbalanced Output ¼" Jack Output | 600Ω
• Mix Unbalanced Output ¼" Jack Output | 600Ω
• Effect Unbalanced Send ¼ Jack Output | 600Ω
• 2TK Play | Unbalanced RCA Left and Right | 10kΩ
• THD | 20-20kHz ← 0.1%
• Noise | -120dB @ Max Gain
• Frequency Response | 20-20kHz, /-2dB
• Inbuilt PSU, IEC Mains Connection
• Dimensions | 415mm (w) 360mm (d) 105mm (h)
