The HE510C is a versatile open reflex optic designed for long gun applications. HE510C is at home on carbines, PCCs, and shotguns due its durable design. HE510C
Features and aluminum housing with titanium hood for added shock resilience and includes a QD absolute co-witness mount (1.41” dot height).
HE510C is packed with Holosun innovations including Solar Failsafe, Shake Awake, MRS (Multi-Reticle System), Green Super LED with up to 50k hour battery life, with 10 daylight and 2 night vision compatible intensity settings. A lower 1/3 co-witness spacer is available separately from Holosun dealers that increases the dot height to 1.63”.
In the Box
- Absolute Cowitness QD Mount
- T10 L Key
- User Manual
- CR2032 Battery
- Lens Cloth
OPTICAL SPECS
| Reticle | 2 MOA Dot & 65 MOA Circle |
| Light Wavelength | 540nm |
| Reticle Color | Red |
| Parallax Free | Yes |
| Unlimited Eye Relief | Yes |
| Magnification | 1x |
| Multi-Coatings | Yes |
ELECTRONIC SPECS
| Power Source | Battery |
| Battery Type | CR2032 |
| Battery Life (Hours) | 50000 |
| Brightness Setting | 10 DL&2 NV |
PHYSICAL SPECS
| Window Size | 0.91x1.26 |
| Dimension (in) | 3.3x1.68x1.78 |
| Weight (oz) | 4.94 |
MECHANICAL SPECS
| Housing Material | Aluminum & Titanium Hood |
| Surface Finish | MAO |
| Adjustment per Click | 0.5 MOA |
| W&E Travel Range | ±50 MOA |
ENVIRONMENT SPECS
| Storage Temperature | -40℃~70℃ |
| Working Temperature | -30℃~60℃ |
| Submersion | IP67 |
| Vibration | 1000G |
