Bring movies to life in smaller spaces with amazing 8K picture quality and true surround sound. Enjoy all your favourite entertainment with 5.2 channel surround sound and wireless music streaming via Bluetooth.

Features - AVR-X580BT
Welcome to 8K Home Theater
Overview
Bring movies to life in smaller spaces with amazing 8K picture quality and true surround sound. Enjoy all your favourite entertainment with 5.2 channel surround sound and wireless music streaming via Bluetooth.

Key Features
True surround sound experience.: Supports Dolby True HD and DTS-HD for high-fidelity, loseless surround sound playback as well as Dolby and DTS umixers upt to 5.1 channels.
Affordable 8K: Supports the latest 8K HDMI technology so you can enjoy amazing picture quality.
Easy music streaming: Stream audio from your favourite music service via Bluetooth from any smart device.
Lag-free gaming: Brings together the latest technologies to ensure a smooth, lag-free gaming expericence.

Powerful, discreet 5-channel amplifier
With up to 130W per channel (at 6 ohms, 1kHz, THD 1%), there is enough power to drive high-quality sound from any speaker.

Dolby True HD
High-fidelity lossless Dolby True HD and Dolby Digital, Dolby Digital Plus signal decoder, and Dolby Pro Logic II up mixer for 2-channel audio signals to createa full 5.1 surround sound experience.

DTS Surround Technology
High-fidelity lossless DTS-HD and DTS Surround, DTS 96/24signal decoding, along with DTSNeo 6 up mixer for 2-channelaudio signals to create a full 5.1surround sound experience.

HDMI Connectivity with ARC/eARC
Supports the latest technology on all HDMI inputs and the output. ARC (Audio Return Channel) or eARC (Enhanced Audio Return Channel) makes playing TV audio through your AV receiver simple with just a single HDMI connection. eARC provides HD and 3D audio transmission such as Dolby True HD, DTS HD Master Audio, and Dolby Atmos while ARC is limited to conventional 5.1ch audio formats or PCM.

8K / HDCP 2.3
Enjoy pristine picture quality ony our 8K TV or projector.8K/60Hz pass-through and 8Kupscaling on 1080p or 4Kcontent is supported on all four HDMI inputs and one output. Supports HDCP 2.3, the late stcopy protection standard, for peace of mind when streaming copy protected content.

Brilliant color from HDR 10
Supports HDR (High Dynamic Range), HLG (Hybrid Log Gamma), as well as Dynamic HDR and HDR10 pass-through. HLG offers HDR technology over broadcast content. Both Dynamic HDR and HDR10 use dynamic metadata to optimize shadows and highlights as screens change.

Dolby Vision
Dolby Vision is a stunning HDR imaging technology that brings extraordinary color, contrast, and brightness to the screen. Compatible with Dolby Vision so you can enjoy Dolby Vision content from a compatible source device and TV.

Next-generation gaming
Supports Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM) for smooth, lag free gaming experience when connected with the compatible gaming devices.

Wireless music streaming via Bluetooth
Enjoy listening to your favorite audio content wirelessly from your smart devices.

High-resolution audio via USB input
Discover the incredible fidelity of high-resolution audio tracks and enjoy music as the artist intended. A front USB port supports up to 24bit/192kHz hires audio playback from a USB drive. Supported audio formats are MP3, WMA, WAV, MPEG-4/AAC, FLAC, and ALAC.

Quick Select
Press one of the four Quick Select buttons on the front panel to easily store and retrieve your favorite audio settings, such as an input source, volume level, or sound mode. You can also access Quick Select buttons on the Denon 500 series remote app downloaded on your phone.

Denon 500 Series Remote App
This iOS or Android control appallows you to turn the receiver on and off, select an in put source, adjust volume level, and browse music from your phoneor in a USB drive when connected to the receiver.

Dual subwoofer outputs
Immerse yourself in evenly distributed, accurate bass. Two subwoofer outputs smooth out low frequencies and provide better dispersion. No audible peaks or dips-just powerful,room-filling bass.

Guided Setup Asisstant on TV
Award-winning Denon Setup Assistant provides simple, clear instructions to get started. Just connect your AV receiver to your TV and follow the instructions on the TV screen to connect your speakers, perform speaker measurements, and connect source devices.

Auto Setup and Room EQ
As part of setup, follow the instructions on your TV to complete speaker setup and measurement using the included microphone. The receiver uses the measurements to optimize sound for the room, bringing the best out of your system. Just sit back and enjoy great sound.

Specifications
Audio section
Power amplifier

Rated out put:

Front:

70 W 70 W (8 /ohms, 20 Hz - 20 kHz with 0.08 % T.H.D.)

90 W 90 W (6 /ohms, 1 kHz with 0.7 % T.H.D.)

Cen ter:

70 W (8 /ohms, 20 Hz - 20 kHz with 0.08 % T.H.D.)

90 W (6 /ohms, 1 kHz with 0.7 % T.H.D.)

Sur round:

70 W 70 W (8 /ohms, 20 Hz - 20 kHz with 0.08 % T.H.D.)

90 W 90 W (6 /ohms, 1 kHz with 0.7 % T.H.D.)

Out put con nec tors:

6 - 16 /ohms

Analog

Input sen si tiv ity/Input im ped ance:

200 mV/47 k /kohms

Fre quency re sponse:

10 Hz - 100 kHz - 1, -3 dB (Di rect mode)

S/N:

98 dB (IHF-A weighted, Di rect mode)

Tuner section
[FM]

[AM]

(Note: V at 75 /ohms, 0 dBf = 1 x 10 -15 W)

Re cep tion fre quency range:

87.5 MHz - 108.0 MHz

522 kHz - 1611 kHz

Ef fec tive sen si tiv ity:

1.2 V (12.8 dBf)

18 V

50 dB sen si tiv ity:

MONO - 2.8 V (20.2 dBf)

S/N ratio:

MONO - 70 dB (IHF-A weighted, Di rect mode)

STEREO - 67 dB (IHF-A weighted, Di rect mode)

Dis tor tion:

MONO - 0.7 % (1 kHz)

STEREO - 1.0 % (1 kHz)

Bluetooth section
Com mu ni ca tions sys tem:

Blue tooth Ver sion 4.2

Trans mis sion power:

0.25 - 10 mW (Class 1)

Max i mum com mu ni ca tion range:

Ap prox. 10 m in line of sight

Fre quency band:

2.4 GHz

Mod u la tion scheme:

FHSS (Fre quency-Hop ping Spread Spec trum)

Sup ported pro files:

A2DP (Ad vanced Audio Dis tri b u tion Pro file) 1.3

AVRCP (Audio Video Re mote Con trol Pro file) 1.6

Cor re spond ing codec:

SBC, AAC

Trans mis sion range (A2DP):

20 Hz - 20,000 Hz

The actual communication range varies depending on the influence of such factors as obstructions between devices, electromagnetic waves from microwave ovens, static electricity, cordless phones, reception sensitivity, antenna performance, operating system, application software etc.

General
Op er at ing tem per a ture:

5 C - 35 C

Power sup ply:

AC 230 V, 50/60 Hz

Power con sump tion:

310 W

Power con sump tion in standby modes:

Standby modes

Set ting items in the menu

Power con sump tion

Blue tooth Standby
link

HDMI Pass Through
link /
HDMI Con trol
link

Nor mal standby

Off

Off

0.1 W

Blue tooth standby

On

Off

1.0 W

Blue tooth standby (Blue tooth, CEC)

On

On

1.3 W

CEC standby

Off

On

0.5 W

What's in the box
1 x Denon AVR-X580BT 5.2 Channel 8K Home Theatre Amplifier
1 x Quick start guide
1 x Cable labels
1 x AM loop antenna
1 x Safety instructions
1 x AVR Sound calibration microphone
1 X Power cord
1 X Remote control(RC-1254)
2 X R03/AAA batteries
